AE-HP-R2

AE-HP-R2 LED Airport Rotating Beacon

Dual-LED rotating beacon to illuminate and draw the pilot's attention to the airport location. Durable and long-lasting with minimal maintenance.

LED as light source ≥100,000 hours typical lamp life
Two heads, two emitting lights
No maintenance
All moving parts are permanently lubricated
Impedance-protected motor eliminates burnouts
12 RPM rotation, 24 flashes/minute
Weatherproof stainless steel cabinet, powder-coated international aviation yellow
Helipad/Heliport/Helideck and Airport applications

ICAO Annex 14 Volume I 5.3.3, FAA L-801, L-802

Specifications	AE-HP-R2 LED Airport Rotating Beacon
Electrical and Illumination Characteristics
Light Source	LED
Emitting Colour	White and yellow, white and green, etc.
Intensity (cd)	25000
Light Beam Center	5° above horizontal
Flash Characteristics	24 flashes per minute
LED Operation Mode	Steady burning
Service Life of LED	>100,000 hours
Power Input	220/240 AC or 110/120 VAC
Circuit Protection	Integrated
Physical Characteristics
Body Material	UV protected polycarbonate
Base Material	Powder-coated stainless steel 304
Mounting	390 X 70 X θ12
Dimension (mm)	566 X 260 X 740
Weight (kg)	22
Product Life Expectancy	Average 5 years
Environmental Factors
Ambient Temperature (°C)	40~85
Humidity	10~90%
Wind Speed	80 m/s
Waterproof	IP66
